PERFORMANCE CURVES OF LARGE ENDSUCTION PUMPS
PERFORMANCE CURVES OF LARGE END SUCTION PUMPS AT 1760 rpm
Performance curves @ 1760rpm
  Delivery Branch Size ( in mm)
Head (in m) 100 125 150 200 250 300 400
150-200       ESL200-675
(250X200-690) 		ESL250-650
(300X250-660)ESL250-600
(350X250-605)		 ESL350-650
(350X300-662) ESL300-665
(350X300-665)
75-150 ESL100-500
(125X100-547) 		ESL125-500
(150x125-547) 		ESL150-500
(200X150-547) 		ESL200-500
(250X200-515) ESL200-450
(250X200-450		 ESL250-500
(300X250-515) ESL300-600
(350X300-600)		 ESL300-550
(350X300-555) ESL300-575
(350X300-595)		 ESL400-500
(450X400-540)
35-75     ESL150-400
(200X150-413) 		ESL200-315
(250X200-342) ESL200-400
(250X200-400)		 ESL250-355
(300X250-364) ESL250-400
(300X250-435)		 ESL300-400
(350X300-390) ESL300-450
(350X300-445)		 ESL400-400
(400X400-384) ESL400-450
(400X400-461)
15-35       ESL200-260
(200X200-260) ESL250-260
(250X250-260)		 ESL250-315
(300X250-315) ESL300-315 (300X300-296)		 ESL300-350
(350X300-340) ESL350-350
(350X350-322)
  160-225
(45-60 )		 225-400
(60-110 )		 430-650
(120-180 )		 650-1000
(180-280 )		 100-1300
(280-360 )		 1300-2200
(360-620 )		 2200-4300
(620-1200 )
  NOMINAL CAPACITY - m3/hr (lps)
PERFORMANCE CURVES OF LARGE END SUCTION PUMPS AT 1480 rpm
Performance curves @ 1480rpm
  Delivery Branch Size ( in mm)
Head (in m) 100 125 150 200 250 300 400
100-140       ESL200-675
(250X200-690) 		ESL250-650
(300X250-660) ESL250-600
(350X250-605)		 ESL350-650
(350X300-662) ESL300-665
(350X300-665)
55-105 ESL100-500
(125X100-547) 		ESL125-500
(150x125-547) 		ESL150-450
(200X150-458) ESL150-500
(200X150-547) 		ESL200-500
(250X200-515) ESL200-450
(250X200-450		 ESL250-500
(300X250-515) ESL300-600
(350X300-600)		 ESL300-550
(350X300-555) ESL300-575
(350X300-595)		 ESL400-500
(450X400-540)
25-55       ESL200-315
(250X200-342) ESL200-400
(250X200-400)		 ESL250-355
(300X250-364) ESL250-400
(300X250-435)		 ESL300-400
(350X300-390) ESL300-450
(350X300-445)		 ESL400-400
(400X400-384) ESL400-450
(400X400-461)
12-25       ESL200-260
(200X200-260) ESL250-260
(250X250-260)		 ESL250-315
(300X250-315) ESL300-315
(300X300-296)		 ESL300-350
(350X300-340) ESL350-350
(350X350-322)
  140-190
(40-55 )		 190-325
(33-90 )		 360-540
(100-150 )		 540-840
(150-235 )		 840-1090
(235-300 )		 1090-1800
(300-500 )		 1800-3600
(500-1000 )
  NOMINAL CAPACITY - m3/hr (lps)
esl1
PERFORMANCE CURVES OF LARGE END SUCTION PUMPS AT 1180 rpm
Performance curves @ 1180rpm
  Delivery Branch Size ( in mm)
Head (in m) 250 300 350 400
60-90   ESL300-650
(350X300-640)ESL300-665
(350X300-665)		 ESL350-650
(400X350-662)
45-60   ESL300-550
(350X300-555)		 ESL350-550
(450X350-540) 		ESL400-500
(450X500-540)
15-45 ESL250-400
(300X250-435)		 ESL300-400
(350X300-390)ESL300-450 (350X300-445)		   ESL400-400
(400X400-384) ESL400-450
(400X400-461)
  450-850
(125-230 )		 850-1600
(230-450)		 950-1800
(260-500)		 1600-2900
(450-800 )
  NOMINAL CAPACITY - m3/hr (lps)
esl1
PERFORMANCE CURVES OF LARGE END SUCTION PUMPS 980 rpm
Performance curves @ 980rpm
  Delivery Branch Size ( in mm)
Head (in m) 250 300 350 400
40-60   ESL300-600
(350X300-600)ESL300-650
(350X300-640)ESL300-665
(350X300-665)		 ESL350-650
(400X350-662)
30-40   ESL300-550
(350X300-555)		 ESL350-550
(450X350-540) 		ESL400-500
(450X500-540)
10-30 ESL250-400
(300X250-435)		 ESL300-400
(350X300-390)ESL300-450 (350X300-445)		   ESL400-400 (400X400-384) ESL400-450
(400X400-461)
  400-700
(100-200 )		 700-1300
(200-350)		 800-1500
(220-420)		 1300-2400
(350-670 )
  NOMINAL CAPACITY - m3/hr (lps)
